MODEL NUMBERS | |||||
FEATURES | 8ft | 10ft | 12ft | 14ft | 16ft |
Overall Length | 11'10" | 14'3" | 16'3" | 18'3" | 20'3" |
Exterior Width | 7'11" | 7'11" | 7'11" | 7'11" | 7'11" |
Exterior Height | 7'6" | 7'6" | 7'6" | 7'6" | 7'6" |
Interior Length | 8'2" | 10'2" | 12'2" | 14'2" | 16'2" |
Interior Width | 5'3" | 5'3" | 5'3" | 5'3" | 5'3" |
Interior Height | 5"6" | 5'6" | 5'6" | 5'6" | 5'6" |
Rear Doors | Double / Single | Double / Single | Double / Single | Double / Single | Double / Single |
Rear Door Width | 5'/NA | 5'/NA | 5'/NA | 5'/NA | 5'/NA |
Rear Door Height | 5' | 5' | 5' | 5' | 5' |
Hitch Weight | 150 lbs. | 150 / 200* lbs. | 175 / 225* lbs. | 200 / 250* lbs. | 225 / 275* lbs. |
Hitch Height | 17" | 18" | 18" | 18" | 18" |
Ball Size | 2" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" |
Platform | 17" | 18" | 18" | 18" | 18" |
G.V.W.R. | 2,900 | 7,000 / 10,000 lbs* | 7,000 / 10,000 lbs* | 7,000 / 10,000 lbs* | 7,000 / 10,000 lbs* |
Curb Weight | 1,400 lbs. | 2,000 lbs. | 2,200 lbs. | 2,350 lbs. | 2,500 lbs. |
Payload Capacity | 1,500 | 4,950 / 7,950* | 4,800 / 7,800* | 4,650 / 7,650* | 4,500 / 7,500* |
Barrel Capacity aprox. | 10 | 25 | 35 | 40 | 50 |
Axles (tandem) | Single | 3,500 / 5,000* | 3,500 / 5,000* | 3,500 / 5,000* | 3,500 / 5,000* |
Brakes | None | Electric | Electric | Electric | Electric |
Tires | ST205 75R15 | ST205 75R15 | ST205 75R15 | ST205 75R15 | ST205 75R15 |
Wheels | 5 Bolt | 5 Bolt / 6 Bolt* | 5 Bolt / 6 Bolt* | 5 Bolt / 6 Bolt* | 5 Bolt / 6 Bolt* |
Frame | 4" Tube | 4" Tube | 4" Tube | 4" Tube / 6" Tube* | 4" Tube / 6" Tube* |
*Heavy Frame Option
Pricing ranges from $11,500 and up. Please contact us for pricing on the size and features you are looking for.
We like to give each customer individual service to quote exactly what you need.
| ||
